3 Years Warranty

• Platform: Desktop
• Market Segment: Enthusiast Desktop
• Product Family: AMD Ryzen™ Processors
• Product Line: AMD Ryzen™ 9 Processors
• AMD PRO Technologies: No
• Consumer Use: Yes
• Regional Availability: Global
• Former Codename: "Raphael AM5"
• Architecture: "Zen 4"
• Number of CPU Cores: 16
• Multithreading (SMT): Yes
• Number of Threads: 32
• Max. Boost Clock: Up to 5.7GHz
• Base Clock: 4.5GHz
• L1 Cache: 1MB
• L2 Cache: 16MB
• L3 Cache: 64MB
• Default TDP: 170W
• Processor Technology for CPU Cores: TSMC 5nm FinFET
• Processor Technology for I/O Die: TSMC 6nm FinFET
• CPU Compute Die (CCD) Size: 71mm²
• I/O Die (IOD) Size: 122mm²
• Package Die Count: 3
• Unlocked for Overclocking: Yes
• AMD EXPO™ Memory Overclocking Technology: Yes
• Precision Boost Overdrive: Yes
• Curve Optimizer Voltage Offsets: Yes
• AMD Ryzen™ Master Support: Yes
• CPU Socket: AM5
• Supporting Chipsets: A620, X670E, X670, B650E, B650
• CPU Boost Technology: Precision Boost 2
• Instruction Set: x86-64
• Supported Extensions: AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
• Thermal Solution (PIB): Not included
• Recommended Cooler: Liquid cooler recommended for optimal performance
• Max. Operating Temperature (Tjmax): 95°C
• Launch Date: 9/27/2022
• *OS Support: Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit (Operating System support will vary by manufacturer)
• Connectivity:
• USB Type-C® Support: Yes
• Native USB 3.2 Gen 2 (10Gbps) Ports: 4
• Native USB 3.2 Gen 1 (5Gbps) Ports: 0
• Native USB 2.0 (480Mbps) Ports: 1
• Native SATA Ports: 0
• PCIe Express® Version: PCIe® 5.0
• Native PCIe® Lanes (Total/Usable): 28 / 24
• Additional Usable PCIe Lanes from Motherboard:
• AMD X670E: 12x Gen4
• AMD X670: 12x Gen4
• AMD B650E: 8x Gen4
• AMD B650: 8x Gen4
• NVMe Support: Boot, RAID0, RAID1, RAID10
• System Memory Type: DDR5
• Memory Channels: 2
• Max. Memory: 128GB
• System Memory Subtype: UDIMM
• Max Memory Speed:
• 2x1R DDR5-5200
• 2x2R DDR5-5200
• 4x1R DDR5-3600
• 4x2R DDR5-3600
• ECC Support: Yes (Requires motherboard support)
• Graphics Capabilities:
• Integrated Graphics: Yes
• Graphics Model: AMD Radeon™ Graphics
• Graphics Core Count: 2
• Graphics Frequency: 2200 MHz
• USB Type-C® DisplayPort™ Alternate Mode: Yes
• Product IDs:
• Product ID Boxed: 100-100000514WOF
• Product ID Tray: 100-000000514
• Key Features:
• Supported Technologies: AMD EXPO™ Technology, AMD Ryzen™ Technologies
