Camera

• Image Sensor:1/2.7" Progressive Scan CMOS
• Shutter Speed:Self-adaptive shutter
• Lens:4mm @ F1.6, viewing angle: 82° (Horizontal), 48° (Vertical), 98° (Diagonal)
• Lens Mount:M12
• Day & Night:IR-cut filter with auto-switching
• DNR:3D DNR
• WDR:Digital WDR

Compression

• Video Compression:H.264/H.265
• Video Bit Rate:Adaptive bit rate.


• Max. Resolution:2304 × 1296
• Frame Rate:Self-Adaptive during network transmission

Network

• Smart Alarm:Motion Detection, Human Shape Detection, Loud Noise Detection
• Wi-Fi Pairing:AP paring
• Protocol:EZVIZ Cloud Proprietary Protocol
• Interface Protocol:EZVIZ Cloud Proprietary Protocol

Interface

• Storage:Supports microSD card (Up to 512 G)
• Power:TYPE-C
• Wired Network:RJ45 X 1 (10M/100M self-adaptive Ethernet port)

Wi-Fi

• Standard:IEEE802.11b, 802.11g, 802.11n
• Frequency Range:2.4 GHz ~ 2.4835 GHz
• Channel Bandwidth:Supports 20MHz
• Security:WPA/WPA2, WPA-PSK/WPA2-PSK
• Transmission Rate:11b: 11Mbps, 11g :54Mbps, 11n :72Mbps
• Output Power(EIRP):19 dBm
• Antenna Gain:1.9 dBi

General

• Operating Conditions:-10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing)
• Power Supply:DC 5V/1A
• Power Consumption:5W max
• IR Range:MAX. 10 meters (33ft)
• Dimensions:88mm x 88.2 mm x 119mm (3.46” x 3.47” x 4.69”)
• Packaging Dimensions:103mm x 103mm x 168mm (4.06” x 4.06” x 6.61”)
• Bare Weight:218g (0.48lb)
