3 Years Warranty

Product Overview:

• Product Collection: 10th Generation Intel® Core™ i5 Processors
• Code Name: Products formerly Comet Lake
• Vertical Segment: Desktop
• Processor Number: i5-10400
• Lithography: 14 nm
• Recommended Customer Price: $200.00 - $210.00
• Use Conditions: PC/Client/Tablet

CPU Specifications:

• Total Cores: 6
• Total Threads: 12
• Max Turbo Frequency: 4.30 GHz
• Intel® Turbo Boost Technology 2.0 Frequency: 4.30 GHz
• Processor Base Frequency: 2.90 GHz
• Cache: 12 MB Intel® Smart Cache
• Bus Speed: 8 GT/s
• TDP: 65 W

Supplemental Information:

• Marketing Status: Launched
• Launch Date: Q2'20
• Embedded Options Available: No
• Datasheet: View now

Memory Specifications:

• Max Memory Size (dependent on memory type): 128 GB
• Memory Types: DDR4-2666
• Max # of Memory Channels: 2
• Max Memory Bandwidth: 41.6 GB/s
• ECC Memory Supported: No

Processor Graphics:

• Processor Graphics ‡: Intel® UHD Graphics 630
• Graphics Base Frequency: 350 MHz
• Graphics Max Dynamic Frequency: 1.10 GHz
• Graphics Video Max Memory: 64 GB
• 4K Support: Yes, at 60Hz
• Max Resolution (HDMI)‡: 4096 x 2160@30Hz
• Max Resolution (DP)‡: 4096 x 2304@60Hz
• Max Resolution (eDP - Integrated Flat Panel)‡: 4096 x 2304@60Hz
• DirectX* Support: 12
• OpenGL* Support: 4.5
• Intel® Quick Sync Video: Yes
• Intel® InTru™ 3D Technology: Yes
• Intel® Clear Video HD Technology: Yes
• Intel® Clear Video Technology: Yes
• of Displays Supported ‡: 3
• Device ID: 0x9BC8 / 0x9BC5

Expansion Options:

• Scalability: 1S Only
• PCI Express Revision: 3.0
• PCI Express Configurations: Up to 1x16, 2x8, 1x8+2x4
• Max # of PCI Express Lanes: 16

Package Specifications:

• Sockets Supported: FCLGA1200
• Max CPU Configuration: 1
• Thermal Solution Specification: PCG 2015C
• TJUNCTION: 100°C
• Package Size: 37.5mm x 37.5mm

Advanced Technologies:

• Intel® Optane™ Memory Supported: Yes
• Intel® Thermal Velocity Boost: No
• Intel® Turbo Boost Max Technology 3.0: No
• Intel® Turbo Boost Technology: 2.0
• Intel® Hyper-Threading Technology: Yes
• Intel® Transactional Synchronization Extensions: No
• Intel® 64: Yes
• Instruction Set: 64-bit
• Instruction Set Extensions: Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
• Idle States: Yes
• Enhanced Intel SpeedStep® Technology: Yes
• Thermal Monitoring Technologies: Yes
• Intel® Identity Protection Technology: Yes

Security & Reliability:

• Intel® AES New Instructions: Yes
• Secure Key: Yes
• Intel® Software Guard Extensions (Intel® SGX): Yes with Intel® ME
• Intel® OS Guard: Yes
• Intel® Trusted Execution Technology: No
• Execute Disable Bit: Yes
• Intel® Boot Guard: Yes
• Intel® Stable IT Platform Program (SIPP): No
• Intel® Virtualization Technology (VT-x): Yes
• Intel® Virtualization Technology for Directed I/O (VT-d): Yes
• Intel® VT-x with Extended Page Tables (EPT): Yes
