CPU Specifications

• Total Cores : 6
• Performance-cores : 6
• Efficient-cores : 0
• Total Threads : 12
• Max Turbo Frequency : 4.40GHz
• Performance-core Max Turbo Frequency : 4.40GHz
• Performance-core Base Frequency : 2.50GHz
• Cache : 18MB Intel® Smart Cache
• Total L2 Cache : 7.5MB
• Processor Base Power : 65W
• Maximum Turbo Power : 117W

Supplemental Information

• Marketing Status : Launched
• Launch Date : Q1'22
• Embedded Options Available : Yes
• Use Conditions : PC/Client/Tablet

Memory Specifications

• Max Memory Size (dependent on memory type) : 128GB
• Memory Types : Up to DDR5 4800 MT/s; Up to DDR4 3200 MT/s
• Max # of Memory Channels : 2
• Max Memory Bandwidth : 76.8GB/s

GPU Specifications

• GPU Name : Intel® UHD Graphics 730
• Graphics Base Frequency : 300MHz
• Graphics Max Dynamic Frequency : 1.45GHz
• Graphics Output : eDP 1.4b, DP 1.4a, HDMI 2.1
• Execution Units : 24
• Max Resolution (HDMI) : 4096 x 2160 @ 60Hz
• Max Resolution (DP) : 7680 x 4320 @ 60Hz
• Max Resolution (eDP - Integrated Flat Panel) : 5120 x 3200 @ 120Hz
• DirectX Support : 12
• OpenGL Support : 4.5
• OpenCL Support : 3.0
• Multi-Format Codec Engines : 1
• Intel® Quick Sync Video : Yes
• Intel® Clear Video HD Technology : Yes
• Display supported: 4

Expansion Options

• Direct Media Interface (DMI) Revision : 4.0
• Max # of DMI Lanes : 8
• Scalability : 1S Only
• PCI Express Revision : 5.0 and 4.0
• PCI Express Configurations : Up to 1x16+4, 2x8+4
• Max # of PCI Express Lanes : 20

Package Specifications

• Sockets Supported : FCLGA1700
• Max CPU Configuration : 1
• Thermal Solution Specification : PCG 2020C
• TJUNCTION : 100°C
• Package Size : 45.0mm x 37.5mm
• Max Operating Temperature : 100°C

Advanced Technologies

• Intel® Gaussian & Neural Accelerator : 3.0
• Intel® Thread Director : No
• Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
• Intel® Optane™ Memory Supported : Yes
• Intel® Speed Shift Technology : Yes
• Intel® Turbo Boost Max Technology 3.0 : No
• Intel® Turbo Boost Technology : 2.0
• Intel® Hyper-Threading Technology : Yes
• Intel® 64 : Yes
• Instruction Set : 64-bit
• Instruction Set Extensions : Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
• Idle States : Yes
• Enhanced Intel SpeedStep® Technology : Yes
• Thermal Monitoring Technologies : Yes
• Intel® Volume Management Device (VMD) : Yes

Security & Reliability

• Intel® Threat Detection Technology (TDT) : Yes
• Intel® Standard Manageability (ISM) : Yes
• Intel® Secure Key : Yes
• Intel® Control-Flow Enforcement Technology : Yes
• Intel® AES New Instructions : Yes
• Intel® OS Guard : Yes
• Execute Disable Bit : Yes
• Intel® Boot Guard : Yes
• Mode-based Execute Control (MBEC) : Yes
• Intel® Virtualization Technology (VT-x) : Yes
• Intel® Virtualization Technology for Directed I/O (VT-d) : Yes
• Intel® VT-x with Extended Page Tables (EPT) : Yes
