CPU Specifications

• Total Cores :10
• # of Performance-cores:6
• # of Efficient-cores:4
• Total Threads :16
• Max Turbo Frequency :4.7 GHz
• Performance-core Max Turbo Frequency :4.7 GHz
• Efficient-core Max Turbo Frequency :3.5 GHz
• Performance-core Base Frequency :2.5 GHz
• Efficient-core Base Frequency :1.8 GHz
• Cache :20 MB Intel® Smart Cache
• Total L2 Cache:9.5 MB
• Processor Base Power :65 W
• Maximum Turbo Power :148 W

Memory Specifications

• Max Memory Size (dependent on memory type) :192 GB
• Memory Types :Up to DDR5 4800 MT/s | Up to DDR4 3200 MT/s
• Max # of Memory Channels :2
• Max Memory Bandwidth :76.8 GB/s

Expansion Options

• Direct Media Interface (DMI) Revision:4.0
• Max # of DMI Lanes:8
• Scalability:1S Only
• PCI Express Revision :5.0 and 4.0
• PCI Express Configurations ‡ :Up to 1x16+4, 2x8+4
• Max # of PCI Express Lanes :20

Package Specifications

• Sockets Supported :FCLGA1700
• Max CPU Configuration:1
• Thermal Solution Specification :PCG 2020C
• TJUNCTION :100°C
• Package Size:45.0 mm x 37.5 mm
• Max Operating Temperature :100 °C

Advanced Technologies

• Intel® Gaussian & Neural Accelerator :3.0
• Intel® Thread Director :Yes
• Intel® Deep Learning Boost (Intel® DL Boost) on CPU :Yes
• Intel® Speed Shift Technology :Yes
• Intel® Turbo Boost Technology ‡ :2.0
• Intel® Hyper-Threading Technology ‡ :Yes
• Intel® 64 ‡ :Yes
• Instruction Set :64-bit
• Instruction Set Extensions :Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
• Idle States :Yes
• Enhanced Intel SpeedStep® Technology :Yes
• Thermal Monitoring Technologies :Yes
• Intel® Volume Management Device (VMD) :Yes

Security & Reliability

• Intel® Standard Manageability (ISM) ‡ :Yes
• Intel® Secure Key :Yes
• Intel® Control-Flow Enforcement Technology :Yes
• Intel® AES New Instructions :Yes
• Intel® OS Guard:Yes
• Execute Disable Bit ‡ :Yes
• Intel® Boot Guard :Yes
• Mode-based Execute Control (MBEC) :Yes
• Intel® Virtualization Technology (VT-x) ‡ :Yes
• Intel® Virtualization Technology for Directed I/O (VT-d) ‡ :Yes
• Intel® VT-x with Extended Page Tables (EPT) ‡ :Yes
