3 Years Warranty

• Chipset: Intel B760
• CPU Support:
• Supports 12th/13th Gen Intel® Coreâ„¢ Processors, Pentium® Gold, and Celeron® Processors
• LGA 1700
• Memory:
• 4x DDR5 Slots
• Maximum Memory Capacity: 192GB
• Memory Support: DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
• Onboard Graphics:
• 2x HDMIâ„¢
• Supports HDMIâ„¢ 2.1 (maximum resolution of 4K 60Hz)
• 2x DisplayPort
• Supports DP 1.4 (maximum resolution of 4K 60Hz)
• *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
• Expansion Slots:
• 2x PCI-E x16 slots
• 1x PCI-E x1 slot
• PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
• PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
• PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
• Storage:
• 2x M.2 slots
• M.2_1 Source (From CPU) supports up to PCIe 4.0 x4, supports 2280/2260/2242 devices
• M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
• 4x SATA 6G
• SATA8 will be unavailable when installing an M.2 SATA SSD in the M2_2 slot.
• RAID: Supports RAID 0, RAID 1, RAID 5, and RAID 10 for SATA storage devices
• USB:
• 2x USB 2.0 ports (Rear)
• 4x USB 2.0 ports (Front)
• 2x USB 3.2 Gen1 Type A ports (Rear)
• 4x USB 3.2 Gen1 Type A ports (Front)
• 1x USB 3.2 Gen1 Type C port (Front)
• 2x USB 3.2 Gen2 Type A ports (Rear)
• LAN: Realtek® RTL8125BG 2.5G LAN
• Wireless / Bluetooth: Intel® Wi-Fi 6E
• Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps
• Supports 802.11 a/b/g/n/ac/ax
• Supports Bluetooth® 5.3, FIPS, FISMA
•
• Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11.
• **Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11.
• Audio: Realtek® ALC897 Codec, 7.1-Channel High Definition Audio
• Internal I/O:
• 1x Power Connector (ATX_PWR)
• 2x Power Connector (CPU_PWR)
• 1x CPU Fan
• 1x Pump Fan
• 2x System Fan
• 2x Front Panel (JFP)
• 1x Chassis Intrusion (JCI)
• 1x Front Audio (JAUD)
• 1x Com Port (JCOM)
• 2x Addressable V2 RGB LED connector (JARGB_V2)
• 1x RGB LED connector(JRGB)
• 1x TPM pin header (Supports TPM 2.0)
• 4x USB 2.0 ports
• 4x USB 3.2 Gen1 Type A ports
• 1x USB 3.2 Gen1 Type C port
• LED Feature: 4x EZ Debug LED
• Back Panel Ports:
• Keyboard / Mouse
• DisplayPort
• USB 3.2 Gen 1 5Gbps (Type-A)
• 2.5G LAN
• Wi-Fi / Bluetooth
• Audio Connectors
• USB 2.0
• HDMIâ„¢
• USB 3.2 Gen 2 10Gbps (Type-A)
• Operating System Support: Windows® 11 64-bit, Windows® 10 64-bit
• PCB Dimension: mATX (243.84mmx243.84mm)
