3 Years Warranty

• Chipset: Intel B760
• CPU Support: Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold, and Celeron® Processors
• Socket: LGA 1700
• Memory:
• 4x DDR5 Slots
• Maximum Memory Capacity: 128GB
• Memory Support: 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC)
• Onboard Graphics:
• Supports HDMI™ 1.4 (maximum resolution of 4K 30Hz)
• Supports DP 1.4 (maximum resolution of 4K 60Hz)
• Supports VGA (maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz)
• Expansion Slots:
• 1x PCI-E x16 slot (PCIe 4.0 x16 from CPU)
• 2x PCI-E x1 slots (PCIe 4.0 x1 from Chipset)
• Storage:
• 2x M.2 slots
• M.2_1 (From CPU) supports PCIe 4.0 x4, supports 2280/2260/2242 devices
• M.2_2 (From Chipset) supports PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
• 4x SATA 6G ports (Note: SATA5 will be unavailable when installing an M.2 SATA SSD in the M2_2 slot.)
• RAID: Supports RAID 0, RAID 1, RAID 5, and RAID 10 for SATA storage devices
• USB:
• 4x USB 2.0 ports (Rear)
• 4x USB 2.0 ports (Front)
• 1x USB 3.2 Gen1 Type-A (Rear)
• 2x USB 3.2 Gen1 Type-A (Front)
• 1x USB 3.2 Gen2 Type-C (Rear)
• LAN: Realtek® RTL8111H Gigabit LAN
• Audio: Realtek® ALC897 Codec, 7.1-Channel High Definition Audio
• Internal I/O:
• Power Connector (ATX_PWR and CPU_PWR)
• CPU Fan
• 2x System Fans
• Front Panel (JFP)
• Chassis Intrusion (JCI)
• Front Audio (JAUD)
• Printer Port (JLPT)
• Com Port (JCOM)
• RGB LED connector (JRGB)
• TPM pin header (Supports TPM 2.0)
• 4x USB 2.0
• 2x USB 3.2 Gen1 Type-A
• LED Feature: 4x EZ Debug LED
• Back Panel Ports:
• VGA
• DisplayPort
• HDMI™
• Keyboard / Mouse
• USB 2.0
• LAN port
• Audio Connectors
• USB 3.2 Gen 1 5Gbps (Type-A)
• USB 3.2 Gen 2 10Gbps (Type-C)
• Operating System Support: Windows® 11 64-bit, Windows® 10 64-bit
• PCB Dimension: mATX (243.84mmx243.84mm)
